Synthetic & Cotton Fabric Processing Mills
Executive Takeaways & Quantified Metrics
- Roll-Level Sub-Lot Tracking: Every raw gray cloth roll receives a unique QR barcode tracking origin weaver, loom number, and GSM weight variance.
- Spectrophotometer Shade Binning: Delta E color coordinates mapped into Odoo lot attributes (Shade A, B, C) ensuring garment cutters receive uniform roll groups.
- Dynamic Dyestuff Recipe Scaling: Liquor ratio and chemical auxiliary dosing automatically adjusted based on actual wet roll moisture pickup.
- Elimination of Re-Dyeing Cost: Slashes chemical re-stripping and bath re-heating costs that erode up to ₹6.5 Lakhs monthly in continuous dye houses.
1. The Shade Matching Nightmare in Continuous Fabric Processing
In the textile hubs of Surat and Ahmedabad, fabric processors deal with an acute quality challenge: shade variance. A batch of 5,000 meters of polyester or viscose fabric is dyed in an automated jet dyeing machine. When dried, finished, and inspected, rolls from the beginning of the batch often exhibit subtle delta-E color variations compared to rolls dyed toward the end of the run.
When rolls of differing shade bands are packed together and delivered to garment export manufacturers, the cutter combines panels from different rolls. The finished shirts or trousers exhibit visible panel-to-panel color mismatch, resulting in 100% shipment rejection and severe financial penalties.
2. Spectrophotometer Delta-E Binning Formulation
Color difference between standard lab dip and production rolls is quantified using the standard CIE Delta-E formulation:
Delta_E = sqrt( (Delta_L*)^2 + (Delta_a*)^2 + (Delta_b*)^2 )Rolls with
Delta_E <= 0.8 are classified as Grade A1 (Export Match).Rolls with
0.8 < Delta_E <= 1.5 are binned into Shade Sub-Lots (B1, B2) and dispatched exclusively to single-shade cut orders.
3. Production Odoo 19 Python ORM Textile Lot Management Blueprint
Below is the Odoo model enforcing shade binning and liquor ratio recipe calculations on production lots:
# -*- coding: utf-8 -*-
from odoo import models, fields, api, _
from odoo.exceptions import ValidationError
class StockLot(models.Model):
_inherit = 'stock.lot'
delta_e_reading = fields.Float(string="Spectro Delta-E", digits=(4, 2))
shade_classification = fields.Selection([
('a1_prime', 'Grade A1 (Prime Export)'),
('b1_sublot', 'Sub-Lot B1 (Domestic Cut)'),
('b2_sublot', 'Sub-Lot B2 (Dark Band)'),
('reject', 'Re-Strip / Re-Dye Required')
], string="Shade Sorting Grade", compute="_compute_shade_grade", store=True)
roll_gross_weight = fields.Float(string="Roll Gross Wt (kg)")
roll_net_meters = fields.Float(string="Finished Length (Meters)")
@api.depends('delta_e_reading')
def _compute_shade_grade(self):
for lot in self:
if not lot.delta_e_reading:
lot.shade_classification = False
elif lot.delta_e_reading <= 0.8:
lot.shade_classification = 'a1_prime'
elif lot.delta_e_reading <= 1.4:
lot.shade_classification = 'b1_sublot'
elif lot.delta_e_reading <= 2.0:
lot.shade_classification = 'b2_sublot'
else:
lot.shade_classification = 'reject'
class MrpProduction(models.Model):
_inherit = 'mrp.production'
liquor_ratio = fields.Float(string="Bath Liquor Ratio (1:X)", default=8.0)
dry_fabric_weight_kg = fields.Float(string="Total Dry Batch Wt (kg)")
calculated_water_liters = fields.Float(string="Process Water (Liters)", compute="_compute_liquor_volume", store=True)
@api.depends('dry_fabric_weight_kg', 'liquor_ratio')
def _compute_liquor_volume(self):
for order in self:
order.calculated_water_liters = order.dry_fabric_weight_kg * order.liquor_ratio
4. Weaving Defect Flagging & Piece-Rate Wage Integration
Inspection tables equipped with touch terminals record 4-point grading system defects (snags, oil spots, missing picks). The Odoo system instantly attributes weaving flaws back to specific subcontracted gray weavers and calculates accurate piece-rate stitching and packaging wages.
5. Mill Deployment & Operational Payoff
Deploying roll-to-roll shade tracking transforms fabric mills from chaotic manual sorting into automated, high-margin export suppliers within 6 weeks of go-live.
